■ Steam Header
■ Textile Machine
■ Gas and Steam Line
■ Water Line |
|
| |
|
|
| |
 |
| Valve
Size |
40A ~ 700A |
| Actuator
Model |
RD50 ~ RD400D |
RS50 ~ RS400D |
| Actuator
Type |
Double Acting |
Single Acting(Spring
Return) |
| Operating
Media |
Compressed Dry Air |
| Operating
Pressure |
4 ~ 7kg/㎠ |
4.5
~ 7kg/㎠ |
| Fluid
Temperature |
PTFE(-20 ~ 160℃) |
RTFE(-20 ~ 180℃) |
MTFE(-30 ~ 195℃) |
316SS(-50 ~ 300℃) |
| Rating |
JIS10K, JIS 20K,
ANSI 150#, ANSI 300# |
| Body
Material |
FCD45, SCPH2, SCS13,
SCS14 |
| Packing
Material |
SCS13, SCS14 |
| Seat
Material |
RTFE, PTFE, MTFE,
316SS |
| Accessory |
Solenoid Valve,
Limit Switch Box, Air Filter &
Regulator, Speed Controller, E/P
Positioner, Declutchable Gear
Box |
|
| ※ () Option |
|
 |
|
| |
|
| |
|
|
|
